The Arlon PCB 33N Polyimide PCB is a high-performance, 4-layer printed circuit board engineered specifically for the extreme thermal and mechanical demands of oil & gas sensor applications. Designed for downhole exploration and industrial logging tools, this board utilizes a specialized polyimide resin system to ensure continuous operation where standard FR-4 materials fail. It provides electronics engineers and procurement managers with a robust, dimensionally stable foundation for critical data acquisition in harsh environments.
Key Features of Arlon 33N Polyimide PCB
-
High Thermal Stability: Features a glass transition temperature ($T_g$) of 250°C to withstand continuous high-temperature exposure.
-
4-Layer Stackup: Optimized layer configuration for clean signal routing, reduced EMI, and dependable power distribution in compact sensor housings.
-
Enhanced Mechanical Properties: Formulated to resist CAF (Conductive Anodic Filament) growth and minimize micro-cracking under severe vibration.
-
Reliable Plated Through-Holes: Excellent Z-axis expansion control prevents barrel cracking during thermal cycling.
-
IPC Class Compliance: Manufactured to IPC-A-600 and IPC-6012 Class 3 standards for high-reliability electronic hardware.
Applications
-
Downhole oil and gas drilling instrumentation and logging-while-drilling (LWD) sensors.
-
Geothermal energy exploration equipment.
-
Aerospace engine control systems and exhaust monitoring sensors.
-
Industrial autoclave controls and high-temperature furnace electronics.
Why Choose PCBSYNC
PCBSYNC is a professional PCB fabrication, PCBA, and EMS manufacturer delivering precision-built electronics for aerospace, medical, automotive, industrial, and smart energy applications. We handle everything from rapid prototyping to mass production — including rigid, flexible, and rigid-flex PCBs, full turnkey assembly, component sourcing, AOI and X-ray inspection, and OEM/ODM support. Reliable boards. Consistent quality. From prototype to production — PCBSYNC.
Get a Custom Quote Today
Ready to integrate high-temperature reliability into your next project? Contact our engineering team to discuss your specific Gerber layouts, stackup requirements, and material specifications, or request a formal quote online.
