Taconic 50 Ohm Impedance-Controlled PCB RF Microwave Manufacturing

Taconic 50 Ohm Impedance-Controlled PCB RF Microwave Manufacturing

Request A Quote

Product Details

Engineers developing advanced telecommunications and radar systems require absolute precision in signal integrity. Our Taconic RF Microwave PCB manufacturing delivers exactly that, providing strict 50 Ohm impedance control for optimal high-frequency performance. Designed for applications where low signal loss and thermal stability are critical, these boards utilise advanced PTFE-based Taconic substrates to maintain a consistent dielectric constant (Dk) even in harsh operating conditions.

  • Impedance Tolerance: Strict 50 Ohm impedance control (typically ±5% to ±10% depending on trace geometry) to prevent signal reflection.

  • Advanced Materials: Fabricated using professional-grade Taconic laminates (such as the TLX, TLY, or RF-35 series) for an exceptionally low dissipation factor (Df).

  • Thermal Reliability: Excellent dimensional stability and consistent Dk across varying temperature profiles.

  • Precision Routing: Tight tolerance trace widths and spacing to support complex microwave printed circuit boards.

  • Surface Finishes: Available in ENIG, Immersion Silver, and bare copper to optimise RF signal transmission.

  • Telecommunications: 5G antenna arrays, base stations, and RF power amplifiers.

  • Aerospace & Defence: Radar systems, satellite communications, and telemetry modules.

  • Automotive: Advanced Driver Assistance Systems (ADAS) and collision avoidance radar.

  • Medical: High-frequency diagnostic imaging equipment.

PCBSYNC is a professional PCB fabrication, PCBA, and EMS manufacturer delivering precision-built electronics for aerospace, medical, automotive, industrial, and smart energy applications. We handle everything from rapid prototyping to mass production — including rigid, flexible, and rigid-flex PCBs, full turnkey assembly, component sourcing, AOI and X-ray inspection, and OEM/ODM support. Reliable boards. Consistent quality. From prototype to production — PCBSYNC.

Submit your Gerber files today to request a quote and connect with our engineering team for your next high-frequency project.
