The Arlon 12-Layer Multilayer PCB is engineered specifically for high-frequency RF microwave and aerospace radar systems. This specialized Arlon PCB utilises AD Series woven fiberglass reinforced PTFE materials to ensure reliable electrical performance in extreme environments. Designed for defence contractors, aerospace engineers, and telecommunications developers, this Arlon Multilayer PCB provides the low insertion loss and precise impedance control required for complex microwave circuitry.
Key Features of the Arlon Multilayer PCB
-
12-Layer Stackup: Advanced multi-layer architecture optimized for high-density routing, signal isolation, and shielding.
-
AD Series Substrate: Utilises woven glass PTFE laminates for superior dimensional stability and a low dissipation factor ($D_f$).
-
Thermal Management: Tailored low coefficient of thermal expansion (CTE) matching copper for reliable solder joints across severe temperature cycles.
-
Precision Control: Tight tolerance control on the dielectric constant ($D_k$) to support stable RF microwave signal propagation.
-
Surface Finish Options: ENIG, ENEPIG, or Immersion Silver options to comply fully with IPC Class 3 aerospace standards.
Applications
-
Aerospace and defence radar tracking systems
-
Satellite communications and space-bound electronic payloads
-
High-frequency RF microwave power amplifiers
-
Commercial telecommunications infrastructure and base stations
