8-Layer HDI PCB – 2+N+2 High-Density Build-Up Board

Product Details

The 8-Layer HDI PCB engineered with a 2+N+2 architecture delivers precise impedance control and advanced routing capabilities for modern, compact devices. Product developers and engineers rely on this specific HDI PCB configuration to achieve superior electrical performance whilst minimising board footprint. The staggered and stacked microvias facilitate dense component placement, making it suitable for high-speed signal transmission and rigorous operational environments.

Key Features of our 8-Layer HDI PCB

Layer Structure: 8 layers with a sequential 2+N+2 high-density build-up configuration.
Microvia Technology: Utilises precision laser-drilled stacked and staggered microvias, alongside blind and buried vias.
Base Materials: Halogen-free FR4 or high-Tg dielectric materials selected to withstand rigorous thermal cycling.
Line Width/Spacing: Advanced etching processes support fine trace widths down to 3 mil / 3 mil.
Surface Finish Options: Electroless Nickel Immersion Gold (ENIG), OSP, or Immersion Silver for optimal component solderability.
Impedance Control: Strict tolerance management ensures reliable high-frequency signal integrity.

Applications

Telecommunications: 5G base stations, network switches, and optical transceivers.
Consumer Electronics: Smartphones, tablets, and advanced wearable technology.
Automotive: Advanced driver-assistance systems (ADAS) and complex infotainment modules.
Medical Equipment: Portable diagnostics and compact patient monitoring instruments.

Why Choose PCBSYNC

PCBSYNC is a professional PCB fabrication, PCBA, and EMS manufacturer delivering precision-built electronics for aerospace, medical, automotive, industrial, and smart energy applications. We handle everything from rapid prototyping to mass production — including rigid, flexible, and rigid-flex PCBs, full turnkey assembly, component sourcing, AOI and X-ray inspection, and OEM/ODM support. Reliable boards. Consistent quality. From prototype to production — PCBSYNC.

To discuss your specific manufacturing requirements or to submit your Gerber files, request a quote today. Our engineering team is ready to review your project.
