Buried Via Core HDI PCB – High Routing Density Build-Up

Product Details

The Buried Via Core HDI PCB provides the essential architecture for next-generation electronic devices that demand extreme component density and processing power. By utilising buried vias within the internal core layers, this high routing density build-up frees up critical surface space, allows for finer line traces, and significantly reduces parasitic capacitance. It is the definitive choice for product developers engineering compact, multi-layered devices that cannot compromise on electrical performance or structural reliability.

Key Features of Buried Via Core HDI PCB Technology

Advanced Build-Up Structure: Utilises sequential lamination with buried and blind microvias to maximise routing layers within a reduced thickness.
High-Density Interconnects: Supports fine pitch components down to 0.4 mm BGA spacing with trace widths and spacing down to 3 mils (0.075 mm).
Premium Base Materials: Available in high-Tg FR-4, halogen-free materials, and low-loss high-frequency laminates (e.g., Rogers, Panasonic Megtron) for superior thermal stability.
Surface Finish Options: ENIG, ENEPIG, and OSP finishes ensure excellent solderability and coplanarity for fine-pitch surface mount technology (SMT).
Strict Quality Standards: Manufactured in compliance with IPC-A-600 Class 2 and Class 3 standards to ensure performance in demanding environments.

Applications

Telecommunications: High-speed routers, switches, and 5G wireless infrastructure modules.
Consumer Electronics: Premium smartphones, wearable technology, and ultra-thin computing devices.
Medical Devices: Compact diagnostic equipment, handheld imaging systems, and patient monitoring implants.
Aerospace & Automotive: Advanced driver-assistance systems (ADAS), engine control units (ECUs), and avionics telemetry boards.
