Arlon Down-Hole PCB 33N Polyimide 4-Layer Oil Gas Sensor Board

Arlon Down-Hole PCB | 33N Polyimide | 4-Layer Oil Gas Sensor Board

Request A Quote

Product Details

The Arlon PCB Down-Hole 4-Layer Oil Gas Sensor Board is engineered specifically for sub-surface exploration and extraction environments. Designed to withstand the punishing thermal and mechanical stresses of down-hole drilling, this board provides reliable signal integrity for critical data logging and sensor systems where standard FR4 materials fail.

Key Features of the Arlon Down-Hole PCB

  • Advanced Material Substrate: Built using Arlon 33N polyimide, featuring a high glass transition temperature ($T_g \ge 250^\circ\text{C}$) to prevent delamination under extreme thermal cycling.

  • 4-Layer Precision Stackup: Optimized layer registration and controlled impedance to ensure precise sensor data transmission.

  • Thermal Dissipation: Excellent thermal stability with minimal Z-axis expansion, protecting plated through-holes from cracking.

  • Chemical & Fluid Resistance: High resistance to drilling fluids, moisture, and corrosive gasses commonly encountered in deep-well operations.

  • Manufacturing Standards: Fully compliant with IPC Class 3 standards for high-reliability electronic applications.

Applications

  • Down-hole logging-while-drilling (LWD) and measurement-while-drilling (MWD) tools.

  • Sub-surface pressure, vibration, and temperature sensor arrays.

  • Industrial geothermal exploration equipment.

  • Heavy-duty oil and gas pipeline monitoring systems.

Why Choose PCBSYNC

PCBSYNC is a professional PCB fabrication, PCBA, and EMS manufacturer delivering precision-built electronics for aerospace, medical, automotive, industrial, and smart energy applications. We handle everything from rapid prototyping to mass production — including rigid, flexible, and rigid-flex PCBs, full turnkey assembly, component sourcing, AOI and X-ray inspection, and OEM/ODM support. Reliable boards. Consistent quality. From prototype to production — PCBSYNC.

If you require robust electronics for your next high-temperature project, contact the PCBSYNC engineering team today to review your Gerber files and request a comprehensive technical quote.
