The RO4350B 6-Layer Medical MRI RF Coil PCB is a high-performance multilayer board engineered for the rigorous demands of diagnostic imaging equipment. Specifically designed for RF coil assemblies, this PCB utilises Rogers RO4350B hydrocarbon ceramic laminates to ensure low dielectric loss and superior dimensional stability. It provides the precise signal-to-noise ratios necessary for high-resolution medical imaging, making it an essential component for medical device engineers and RF specialists.
Key Features
-
Base Material: Rogers RO4350B (High-frequency hydrocarbon ceramic laminate)
-
Layer Count: 6-layer multilayer construction for complex signal routing
-
Board Thickness: 1.6mm ($\pm$10%)
-
Copper Weight: 1oz (35$\mu$m) finished copper for optimal conductivity
-
Surface Finish: ENIG (Electroless Nickel Immersion Gold) for superior solderability and oxidation resistance
-
Dielectric Constant ($D_k$): $3.48 \pm 0.05$ at 10 GHz
-
Dissipation Factor ($D_f$): 0.0037 at 10 GHz
-
Compliance: RoHS compliant and manufactured to IPC Class 2 or 3 standards
Applications
The RO4350B 6-Layer Medical MRI RF Coil PCB is primarily utilised in the healthcare and scientific research sectors. Key use cases include:
-
Magnetic Resonance Imaging (MRI) surface coils and volume coils
-
RF signal processing units in diagnostic medical machinery
-
High-frequency power amplifiers for medical therapeutics
-
Precision microwave components and phased array antennas
