Product Overview
The PCBSync 5G Telecom Rigid-Flex PCB with Rogers Material is an industry-leading printed circuit board solution purpose-built for next-generation 5G telecommunications infrastructure, mmWave antenna arrays, RF front-end modules, and high-speed signal processing systems. Combining the mechanical stability of rigid PCB sections with the dynamic flexibility of polyimide flex layers, this advanced rigid-flex PCB eliminates costly connectors, reduces signal loss, and enables compact, high-density packaging in demanding telecom enclosures.
Engineered with premium Rogers high-frequency laminates — including Rogers 4003C, Rogers 4350B, and RO3003 — this 5G rigid-flex PCB achieves exceptionally low dielectric loss (Df), stable dielectric constant (Dk), and tight impedance tolerance across wide temperature and frequency ranges. Whether you are designing 5G base station (gNB) radio units, small cells, phased-array antenna systems, or telecom backhaul equipment, PCBSync delivers the precision, reliability, and scalability your product demands.
Key Features & Benefits
Rogers High-Frequency Laminate Technology
- Rogers 4003C, 4350B, and RO3003 material options for sub-6 GHz and mmWave 5G NR bands
- Ultra-low dielectric loss (Df as low as 0.0013 at 10 GHz) for minimal signal attenuation
- Stable dielectric constant (Dk 3.0–3.5 ±0.05) across temperature and frequency
- Superior thermal conductivity for high-power 5G PA modules and power amplifiers
- Halogen-free and RoHS-compliant Rogers laminates available on request
Advanced Rigid-Flex PCB Construction
- 2–20 layer rigid-flex stackup supporting complex 5G multi-band RF architectures
- Polyimide (PI) flex core with acrylic or non-acrylic adhesive for dynamic and static flex zones
- Laser-drilled microvias (as small as 75 µm) and blind/buried via structures for high-density interconnect
- Controlled impedance traces (±5% tolerance) for 50Ω single-ended and 100Ω differential 5G RF lines
- Coverlay and stiffener integration for mechanical protection in connector and component areas
5G Telecom Performance & Reliability
- Engineered for 5G NR frequency bands: n77, n78, n79 (sub-6 GHz) and n257, n258, n261 (mmWave 24–40 GHz)
- Low passive intermodulation (PIM) design supporting Class B (<−153 dBc) telecom antenna requirements
- Thermal cycling tested from −40°C to +125°C for outdoor gNB and small cell deployments
- IPC-6013 Class 3 qualification for mission-critical telecom and defense-grade 5G applications
- UL 94V-0 flame retardancy; IP67-compatible enclosure-ready rigid-flex configurations available
Technical Specifications
| Parameter |
Specification |
| PCB Type |
Rigid-Flex (Rigid + Flexible Zones) |
| Base Material (Rigid) |
Rogers 4003C / 4350B / RO3003 |
| Base Material (Flex) |
Polyimide (PI), 1/2 oz or 1 oz copper |
| Layer Count |
2–20 layers (custom stackup available) |
| Dielectric Constant (Dk) |
3.0 – 3.55 ±0.05 @ 10 GHz |
| Dissipation Factor (Df) |
0.0013 – 0.0031 @ 10 GHz |
| Frequency Range |
DC to 40 GHz (5G sub-6 GHz & mmWave) |
| Minimum Trace/Space |
50 µm / 50 µm (HDI) |
| Min. Drill Size |
75 µm (laser microvia) |
| Copper Thickness |
H/H oz, 1 oz, 2 oz (rigid); H/H oz, 1 oz (flex) |
| Surface Finish |
ENIG, ENEPIG, Immersion Silver, OSP |
| Impedance Control |
±5% single-ended & differential |
| Board Thickness (Rigid) |
0.4 mm – 3.2 mm |
| Flex Bend Radius (Min.) |
6× flex thickness (dynamic); 3× (static) |
| Operating Temperature |
−40°C to +125°C |
| Quality Standard |
IPC-6013 Class 2 / Class 3; ISO 9001:2015 |
| Certifications |
UL, RoHS, REACH, IPC-A-600 |
| Lead Time |
Standard: 10–15 days | Express: 3–5 days |
| Minimum Order Quantity |
1 prototype / 10 production units |
5G Telecom Applications
The PCBSync 5G Rigid-Flex PCB with Rogers Material is the preferred choice for engineers and procurement teams sourcing high-frequency PCBs for:
- 5G NR Base Stations (gNB) & Radio Units (RU) — Massive MIMO, beamforming, and active antenna units (AAU)
- mmWave Phased-Array Antenna Systems — 28 GHz, 37 GHz, and 39 GHz radar and communication modules
- 5G Small Cells & Femtocell Nodes — Indoor and outdoor ultra-dense network deployments
- RF Front-End Modules (FEM) — Low-noise amplifiers (LNA), power amplifiers (PA), and T/R switches
- 5G Core Network Equipment — High-speed backhaul routers, switches, and optical transport hardware
- Telecom Test & Measurement Instruments — Vector network analyzers, signal generators, and spectrum analyzers
- Defense & Aerospace AESA Radar — Military 5G, satellite communications, and electronic warfare modules
- Autonomous Vehicle V2X Modules — Cellular vehicle-to-everything (C-V2X) on 5G NR sidelink
Why Choose PCBSync for 5G Rogers Rigid-Flex PCBs?
| PCBSync Advantage |
Customer Benefit |
| Rogers-Certified Laminate Processing |
Guaranteed material integrity & RF performance |
| In-house Impedance Testing (TDR & VNA) |
Every board verified to spec before shipment |
| DFM & DFT Engineering Support |
Reduce NPI cycles and time-to-market |
| AS9100D Aerospace Capability |
Defense-grade quality for mission-critical 5G |
| IPC Class 3 Production Lines |
Zero-defect reliability for harsh environments |
| One-stop Rigid-Flex + Assembly (PCBA) |
Simplify supply chain, reduce landed cost |
| Prototype-to-Volume Scalability |
From 1 prototype to 100,000+ volume runs |
| NDA & IP Protection Programs |
Secure your 5G design confidentiality |
