The RO4003C 10-Layer Optical Line Terminal Board is a precision-engineered solution designed for high-speed data transmission and telecommunications infrastructure. Specifically developed for Optical Line Terminal (OLT) applications, this multilayer PCB utilizes Rogers RO4003C hydrocarbon ceramic laminates to ensure low dielectric loss and thermal stability under demanding operational loads. It is an essential component for network engineers and system integrators focusing on fiber-to-the-x (FTT x) deployments.
Key Features of RO4003C 10-Layer OLT Board
-
Material: High-frequency Rogers RO4003C laminate for stable dielectric constant (Dk).
-
Layer Count: 10-layer high-density interconnect (HDI) stackup.
-
Board Thickness: 1.8mm for enhanced mechanical rigidity.
-
Copper Weight: 1oz finished copper for balanced thermal management and conductivity.
-
Surface Finish: Electroless Nickel Immersion Gold (ENIG) for superior oxidation resistance and solderability.
-
Impedance Control: Tight tolerance matching for high-speed differential signal pairs.
-
Compliance: RoHS compliant and manufactured to IPC Class 2/3 standards.
Applications
The versatility and signal stability of this board make it ideal for:
-
Telecommunications: OLT hardware, broadband access equipment, and 5G base stations.
-
Data Centres: High-speed switching and routing modules.
-
Optical Networking: Signal processing for fiber optic transceivers and GPON systems.
-
Radio Frequency: High-bandwidth microwave and RF circuitry.
Why Choose PCBSYNC
PCBSYNC is a professional PCB fabrication, PCBA, and EMS manufacturer delivering precision-built electronics for aerospace, medical, automotive, industrial, and smart energy applications. We handle everything from rapid prototyping to mass production — including rigid, flexible, and rigid-flex PCBs, full turnkey assembly, component sourcing, AOI and X-ray inspection, and OEM/ODM support. Reliable boards. Consistent quality. From prototype to production — PCBSYNC.
For detailed technical specifications or to discuss your custom stackup requirements, please reach out to our engineering team or request a formal quote today.
