The Arlon CLTE-XT 6-layer PCB provides the electrical stability and thermal robustness required for next-generation 5G mmWave antenna systems. Built on advanced Arlon PCB laminates, this construction minimizes signal loss and maintains a consistent dielectric constant of 2.94 across a wide temperature range, ensuring your designs perform reliably in challenging operational environments.
Key Features
-
Material: Arlon CLTE-XT laminate with a stable $D_k$ of 2.94.
-
Layer Count: 6-layer stack-up optimized for high-speed signal routing.
-
Thermal Stability: Excellent coefficient of thermal expansion (CTE) matching for copper, ensuring reliability during reflow cycles.
-
Low Loss: Engineered for low dissipation factor ($D_f$) to support high-frequency transmission.
-
Manufacturing Standards: Fabricated to IPC-Class 2 or Class 3 standards based on your specific requirements.
Applications
This 6-layer configuration is designed for high-frequency connectivity and data-dense environments:
-
5G mmWave antenna modules and phased array antennas.
-
Radar and satellite communication systems.
-
High-speed wireless infrastructure and backhaul equipment.
-
RF test and measurement instrumentation.
Why Choose PCBSYNC
PCBSYNC is a professional PCB fabrication, PCBA, and EMS manufacturer delivering precision-built electronics for aerospace, medical, automotive, industrial, and smart energy applications. We handle everything from rapid prototyping to mass production — including rigid, flexible, and rigid-flex PCBs, full turnkey assembly, component sourcing, AOI and X-ray inspection, and OEM/ODM support. Reliable boards. Consistent quality. From prototype to production — PCBSYNC.
Ready to start your next RF design project? Submit your Gerber files today and request a quote for your Arlon CLTE-XT project specifications.
